200G QSFP56

The 200G QSFP56 is a pluggable transceiver. Each channel operates with PAM4 modulation scheme at 26.5625G baud rate.

How To BuyContact us sales@cloudoptics.net

DESCRIPTION

200G QSFP56
  • QSFP-DD MSA compliant
  • Compliant with IEEE 802.3cd 200GBASE-SR4 and CEI-56G-VSR-PAM4
  • Bi-directional operation: 4x Tx, and 4x Rx at 53.125Gb/s with 26.5625Gbd PAM4 modulation scheme
  • Built in Analog CDR
  • MPO-12 APC optical interface
  • Enabled by 850nm VCSEL
  • Operating case temperature 0°C – 70°C
  • Hot pluggable
  • Max Power consumption 4W per end
  • Transmission distance up to 100m with OM3 MM fiber
  • Laser eye safety Class 1M
  • Management interface based on SFF-8636
